Descripción

• Socket Intel® LGA 1200: Lista para procesadores Intel® Core ™ de 10a generación.
• 5X Protection III: Múltiples protecciones de hardware para una protección integral.
• ASUS OptiMem: Cuidadoso de trazas y vías para preservar la integridad de la señal para mejorar la estabilidad de la memoria.
• Conectividad ultrarrápida: M.2, Ethernet de 1 Gb, USB 3.2 Gen 1 Tipo-A.
• CPU Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors *
• Chipset Intel® H410
• Memoria 2 x DIMM, Max. 64GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *
• Gráficos
• Integrated Graphics Processor *
  1 x D-Sub
  1 x HDMI 1.4b
  *Graphics specifications may vary between CPU types.
• Slots de Expansión
  Intel® 10th Gen Processors
  1 x PCIe 3.0 x16 (x16 mode)
  Intel® H410 Chipset
  2 x PCIe 3.0 x1
  Almacenamiento
  Total supports 1 x M.2 slots and 4 x SATA 6Gb/s ports
• Intel® H410 Chipset :
  1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)*1
  4 x SATA 6Gb/s port(s)
• LAN Realtek® RTL8111H
• Audio
  Realtek ALC887 7.1-Channel High Definition Audio CODEC *2
  – Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback
  Audio Feature :
  – LED-illuminated design
  – Audio Shielding
  – Dedicated audio PCB layers
  – Premium Japanese audio capacitors
• Puertos USB
  Rear USB Port ( Total 4 )
  2 x USB 3.2 Gen 1 port(s)(2 x Type-A)
  2 x USB 2.0 port(s)(2 x Type-A)
  Front USB Port ( Total 6 )
  2 x USB 3.2 Gen 1 port(s)
  4 x USB 2.0 port(s)
• Software Features
  ASUS Exclusive Software
  Armoury Crate
  AI Suite 3
  – Performance And Power Saving Utility
  TurboV EVO
  EPU
  Digi+ VRM
  Fan Xpert
  – EZ update
  ASUS CPU-Z
  AI Charger
  DAEMON Tools
  Norton Anti-virus software (Free Trial for 60 days)
  WinRAR
• UEFI BIOS
  ASUS EZ DIY
  – ASUS CrashFree BIOS 3
  – ASUS EZ Flash 3
  – ASUS UEFI BIOS EZ Mode
  ASUS Special Features
  ASUS 5X PROTECTION III
  – ASUS DIGI+ VRM
  – ASUS LANGuard
  – ASUS Overvoltage Protection
  – ASUS SafeSlot Core
  – ASUS Stainless-Steel Back I/O
  ASUS Q-Design
  – ASUS Q-DIMM
  – ASUS Q-Slot
  ASUS Thermal Solution
  – Aluminum heatsink design
• Puertos I/O Traseros
  1 x PS/2 keyboard (purple)
  1 x PS/2 mouse (green)
  1 x D-Sub
  1 x HDMI
  1 x LAN (RJ45) port(s)
  2 x USB 3.2 Gen 1 Type-A
  2 x USB 2.0
  3 x Audio jack(s)
• Internal I/O
  1 x CPU Fan connector(s)
  1 x Chassis Fan connector(s)
  1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
  2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)
  1 x COM port(s) connector(s)
  4 x SATA 6Gb/s connector(s)
  1 x S/PDIF out header(s)
  1 x 24-pin EATX Power connector(s)
  1 x 8-pin EATX 12V Power connectors
  1 x Front panel audio connector(s) (AAFP)
  1 x Clear CMOS jumper(s)
  1 x System panel connector
  1 x Speaker connector
• Accessorios
  I/O Shield
  2 x SATA 6Gb/s cable(s)
  1 x M.2 Anchor
  1 x Supporting DVD
  User manual
• BIOS
  128 Mb Flash ROM, UEFI AMI BIOS
• Capacidad de gestión
  WOL by PME, PXE
• Sistema Operativo Windows® 10 64-bit
  mATX Form Factor 22.6 cm x 20.3 cm
