Descripción
- Msi Pro B760M-P
- Chipset INTEL B760
- CPU Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors LGA 1700
- Memory 4x DDR4, Maximum Memory Capacity 128GB
- Onboard Graphics
- 1x HDMI™
- 1x DisplayPort
- 1x D-Sub
- Slot
- 1x PCI-E x16 slot (Qty)
- 2x PCI-E x1 slot (Qty)
- Audio Realtek® ALC897 Codec
- 7.1-Channel High Definition Audio
- Storage
- 2x M.2 (Qty)
- 4x SATA 6G (Qty)
- USB
- 4x USB 2.0 (Rear)
- 4x USB 2.0 (Front)
- 1x USB 5Gbps Type A (Rear)
- 2x USB 5Gbps Type A (Front)
- 1x USB 10Gbps Type C (Rear)
- LAN Realtek® RTL8111H Gigabit LAN
- Internal IO
- 1x Power Connector(ATX_PWR)
- 1x Power Connector(CPU_PWR)
- 1x CPU Fan
- 2x System Fan
- 2x Front Panel (JFP)
- 1x Chassis Intrusion (JCI)
- 1x Front Audio (JAUD)
- 1x Printer Port (JLPT)
- 1x Com Port (JCOM)
- 1x RGB LED connector(JRGB)
- 1x TPM pin header(Support TPM 2.0)
- 4x USB 2.0 ports
- 2x USB 5Gbps Type A ports
- mATX 243.84mmx243.84mm
